Tin Roof Adjustable Mounting Solution
AZP Adjustable Mounting Solution is lightweight with good strength and great corrosion stability. You can choose the best installation angle according to the longitude and latitude.
● Max wind capacity:42M/S
● Max snow capacity: 1KN/M
● Span range:0.6-2.5M
● Installation angle deviation∶±2°
● Adjustable angle∶10°-15，15R-30，30°-60°
● Design standard:AS/NZS1170,ASCE 7-05,DIN1044,BSEN1990:2002,BSEN1991-1-3:2000,BSEN199-1-4:2005
● Installation site:Tin roof
● Main material:AL6005-T5
● Fastener material: SuS304
● Applicable modules∶Frame
● Component arrangement∶Horizontal/Vertical
● Warranty Period:10years
