Tin Roof Railless Mounting Solution
AZP Railless Mounting Solution is widely used in large scale warehouse and workshop tin roofs.They are mounted directly without any perforation, which cause no damages to the roof. Without the rail, it's very easy to install, structural durable and cost-effective .
● Max wind capacity:42M/S
● Max snow capacity: 2KN/M2
● Span range∶Customized to the tin roof
● Design standard:AS/NZS1170,ASCE 7-O5,DIN1044,GB50797-2012,GB5009-2012,BSEB1990:2002,BSEN199-1-3:2000,BSEN199-1-4:2005
● Installation site:Tin roof
● Main material:AL6005-T5/SUS304
● Fastener material: SUS304
● Applicable modules∶Frame or frameless
● Component arrangement∶Horizontal /Vertical
● Warranty Period∶10 years
